SKF10 - Kinetic Light with Pylon K2

Name: SKF100 Light
Brand: Trulife
SKU: SKF100-22-L-1A2
Price: 419.0 USD
Availability: InStock

SKU SKF100-22-L-1A2

Version: SKF100 Light

Size & Side

Keel Category

K2 foot with integrated multi-axial ankle
Proximal male pyramid
Full length, composite keel
Sandal toe foot shell (non-removable)
Integrated ankle function for all categories is the same as the existing Kinetic

Indications

Moderate impact level, K2, maximum weight of 160 kg /350 lb*

Specifications

Product Sizes			22-30 cm
Weight Limit			160 kg · 350 lb *For category #5
Toe			Sandal Toe
Foot Shell			Light, Dark
Product Weight			Cat 1-2: 481 g · 1.1 lb (Size 25 without Pylon)
			Cat 3-5: 564 g · 1.2 lb (Size 25 without Pylon)
Min. Clearance			7.3 cm · 2.9 in
Heel Rise			9.5 mm · 3/8 in
Includes			Preassembled with Female Pylon AAA200

Category selection instruction

Bumper Selection Instructions

To optimize selection, follow the three steps below to determine the appropriate category.

1. Locate the column associated with the amputee’s foot length.

2. Locate the row corresponding to the amputee’s weight.

3. The area where the column and row intersect lists the appropriate category.

Important Note: If the amputee has a long BK or carries heavy loads choose the next category higher.

Warning: Choosing a lower category than what is suggested based on the above procedure and patient data will void the warranty. If your patient’s weight exceeds the limits of the chart, please contact Trulife Customer Service.

Foot Length	22	23	24	25	26	27	28	29	30
Patient Weight
137-160 kg · 301-350 lb	–	–	–	–	5	5	5	5	5
101-136 kg · 221-300 lb	–	–	4	4	4	4	4	4	4
81-100 kg · 177-220 lb	–	2	3	3	3	3	3	3	–
< 80 kg · < 176 lb	1	1	2	2	2	2	2	–	–
